REVODATA 3 Port Outdoor Gigabit PoE Extender, 10/100/1000 Mbps PoE Repeater 100/250 Meter Extend, IEEE802.3af/at 3 PoE Output Waterproof for Outdoor,

Note:
1. This Extender is not a PoE Switch, it can not work without powered from PoE Switch/PoE injector/PoE NVR.
2. Please don't place any heavy thing on the PoE extender;

Overview:
3*100/1000mbps POE port to output, 1*100/1000mbps port to input
100m Distance and VLAN, IP65
Support IEEE802.3AF/AT
POE In:44V-57V/30W;
POE Output (1-3) :POE 48V, Power: 10w-25W(max)
All port supported by MDI/MDIX auto flip and self negotiation
Supply 4 100/1000Mpbs adaptive high speed forwarding data packet

Specification:
PoE input: 1 RJ45 port
PoE output: 3 RJ45 port
Input power: 30 Watts Max
Output power: 10-25 Watts
Ethernet Rate: 10/100/1000Mbps
Network Medium: Cat5 or better UTP cable (less than 100m)
Daisy Chain Distance: up to 700m(6 pieces)
Repeater Mode: Store and forward
MAC Address Table: 1K
Switching Capacity: 10Gbps
PoE Standard: IEEE 802.3af/at
Power input Pin: 1/2+、3/6- 、4/5+、7/8
Power output Pin: 1/2+、3/6-
Storage Humidity: 5%~90%, No Condensation
Operating temperature: -10～45℃
Dimension: 98 x 148 x 34mm (L*W*H)
Weight: 150g

Package Contents:
1 x WPOE6004G
